    Learning Objective

    • interpret the stereoisomerism of compounds with three or more chiral centers

    Possible Number of Stereoisomers

    In general, a structure with n stereocenters will have 2n different stereoisomers. (We are not considering, for the time being, the stereochemistry of double bonds – that will come later). For example, let's consider the glucose molecule in its open-chain form (recall that many sugar molecules can exist in either an open-chain or a cyclic form). There are two enantiomers of glucose, called D-glucose and L-glucose. The D-enantiomer is the common sugar that our bodies use for energy. It has n = 4 stereocenters, so therefore there are 2n = 24 = 16 possible stereoisomers (including D-glucose itself).

    In L-glucose, all of the stereocenters are inverted relative to D-glucose. That leaves 14 diastereomers of D-glucose: these are molecules in which at least one, but not all, of the stereocenters are inverted relative to D-glucose. One of these 14 diastereomers, a sugar called D-galactose, is shown above: in D-galactose, one of four stereocenters is inverted relative to D-glucose. Diastereomers which differ in only one stereocenter (out of two or more) are called epimers. D-glucose and D-galactose can therefore be refered to as epimers as well as diastereomers.

    The epimer term is useful because in biochemical pathways, compounds with multiple chiral centers are isomerized at one specific center by enzymes known as epimerases. Two examples of epimerase-catalyzed reactions are below.

    alt

    Now, let's extend our analysis to a sugar molecule with three chiral centers. Going through all the possible combinations, we come up with eight total stereoisomers - four pairs of enantiomers.

    alt

    Let's draw the RRR stereoisomer. Being careful to draw the wedge bonds correctly so that they match the RRR configurations, we get:

    alt

    Now, using the above drawing as our model, drawing any other stereoisomer is easy. If we want to draw the enantiomer of RRR, we don't need to try to visualize the mirror image, we just start with the RRR structure and invert the configuration at every chiral center to get SSS.

    alt

    Try making models of RRR and SSS and confirm that they are in fact nonsuperimposable mirror images of each other.

    There are six diastereomers of RRR. To draw one of them, we just invert the configuration of at least one, but not all three, of the chiral centers. Let's invert the configuration at chiral center 1 and 2, but leave chiral center 3 unchanged. This gives us the SSR configuration.

    alt

    One more definition at this point: diastereomers which differ at only a single chiral center are called epimers. For example, RRR and SRR are epimers:

    alt

    The RRR and SSR stereoisomers shown earlier are diastereomers but not epimers because they differ at two of the three chiral centers.

    Example \(\PageIndex{1}\)

    1. Draw the structure of the enantiomer of the SRS stereoisomer of the sugar used in the previous example.
    2. List (using the XXX format, not drawing the structures) all of the epimers of SRS.
    3. List all of the stereoisomers that are diastereomers, but not epimers, of SRS.

    Solutions to exercises

    Solution

    Add text here.

    Example \(\PageIndex{2}\)

    The sugar below is one of the stereoisomers that we have been discussing.

    alt

    The only problem is, it is drawn with the carbon backbone in a different orientation from what we have seen. Determine the configuration at each chiral center to determine which stereoisomer it is.

    Exercise \(\PageIndex{3}\)

    Draw the enantiomer of the xylulose-5-phosphate structure in the previous figure.

    Exercise \(\PageIndex{4}\)

    The structure of the amino acid D-threonine, drawn without stereochemistry, is shown below. D-threonine has the (S) configuration at both of its chiral centers. Draw D-threonine, it's enantiomer, and its two diastereomers.

    alt

    Answer

    Solutions to exercises

    Comparing Stereoisomerism with Structural Isomerism

    D-glucose and D-fructose are not stereoisomers, because they have different bonding connectivity: glucose has an aldehyde group, while fructose has a ketone. The two sugars do, however, have the same molecular formula, so by definition they are constitutional isomers.

    alt

    D-glucose and D-ribose are not isomers of any kind, because they have different molecular formulas.

    alt

    Exercise 5: Identify the relationship between each pair of structures. Your choices are: not isomers, constitutional isomers, diastereomers but not epimers, epimers, enantiomers, or same molecule

    alt

    Exercise 6: Identify the relationship between each pair of structures. Hint - figure out the configuration of each chiral center.

    alt

    Solutions to exercises

    Kahn Academy video tutorial on stereoisomeric relationships

    Organic Chemistry With a Biological Emphasis by Tim Soderberg (University of Minnesota, Morris)
