    Closely related to the concept of chirality, and particularly important in biological chemistry, is the notion of prochirality. A molecule is said to be prochiral if it can be converted from achiral to chiral in a single chemical step. For instance, an unsymmetrical ketone like 2-butanone is prochiral because it can be converted to the chiral alcohol 2-butanol by the addition of hydrogen, as we’ll see in Section 17.5.

    The figure shows a reaction in which 2-butanone (prochiral) forms 2-butanol (chiral). C2 in both structures is highlighted.

    Which enantiomer of 2-butanol is produced depends on which face of the planar carbonyl group undergoes reaction. To distinguish between the possibilities, we use the stereochemical descriptors Re and Si. Rank the three groups attached to the trigonal, sp2-hybridized carbon, and imagine curved arrows from the highest to second-highest to third-highest ranked substituents. The face on which the arrows curve clockwise is designated the Re face (similar to R), and the face on which the arrows curve counterclockwise is designated the Si face (similar to S). In this example, addition of hydrogen from the Re face gives (S)-2-butane, and addition from the Si face gives (R)-2-butane.

    2-Butanone is labeled Si face (counterclockwise) at the bottom and Re face (clockwise) at the top. To the right, the structures of (S)-2-butanol and (R)-2-butanol are drawn.

    In addition to compounds with planar, sp2-hybridized atoms, compounds with tetrahedral, sp3-hybridized atoms can also be prochiral. An sp3-hybridized atom is said to be a prochirality center if, by changing one of its attached groups, it becomes a chirality center. The −CH2OH carbon atom of ethanol, for instance, is a prochirality center because changing one of its attached −H atoms converts it into a chirality center.

    The structure of ethanol with prochiral C2 labeled. Forms another compound, in which the C2 is bonded to X instead of hydrogen and labeled chirality center.

    To distinguish between the two identical atoms (or groups of atoms) on a prochirality center, we imagine a change that will raise the ranking of one atom over the other without affecting its rank with respect to other attached groups. On the −CH2OH carbon of ethanol, for instance, we might imagine replacing one of the 1H atoms (protium) by 2H (deuterium). The newly introduced 2H atom ranks higher than the remaining 1H atom, but it remains lower than other groups attached to the carbon. Of the two identical atoms in the original compound, the atom whose replacement leads to an R chirality center is said to be pro-R and the atom whose replacement leads to an S chirality center is pro-S.

    The structure of ethanol with prochiral C2 labeled leads to the formation of two chiral compounds, one with C2 labeled R and other with C2 labeled S.

    A large number of biological reactions involve prochiral compounds. One of the steps in the citric acid cycle by which food is metabolized, for instance, is the addition of H2O to fumarate to give malate. Addition of −OH occurs on the Si face of a fumarate carbon and gives (S)-malate as product.

    The figure shows a reaction where fumarate converts to (S)-malate. In fumarate, the central carbon is labeled Re at the top and Si at the bottom.

    As another example, studies with deuterium-labeled substrates have shown that the reaction of ethanol with the coenzyme nicotinamide adenine dinucleotide (NAD+), catalyzed by yeast alcohol dehydrogenase, occurs with exclusive removal of the pro-R hydrogen from ethanol and with addition only to the Re face of NAD+.

    The figure shows a reversible reaction where ethanol reacts with N A D superscript plus to form acetaldehyde and N A D H.

    Determining the stereochemistry of reactions at prochirality centers is a powerful method for studying detailed mechanisms in biochemical reactions. As just one example, the conversion of citrate to cis-aconitate in the citric acid cycle has been shown to occur with loss of a pro-R hydrogen, implying that the OH and H groups leave from opposite sides of the molecule.

    The figure shows a reaction where citrate on the elimination of water molecules by the loss of the pro-R-hydrogen forms cis-aconitate.
    Exercise \(\PageIndex{1}\)

    Identify the indicated hydrogens in the following molecules as pro-R or pro-S:

    1. The wedge-dash structure of (S)-glyceraldehyde. Two arrows point toward the hydrogen atoms bonded at C3.
    2. The wedge-dash structure of phenylalanine. Two arrows point toward the hydrogen atoms bonded at C3.
    Answer
    1. The wedge-dash structure of (S)-glyceraldehyde. The dash bonded hydrogen at C3 is labeled pro-R and wedge bonded hydrogen is labeled pro-S.
    2. The wedge-dash structure of an amino acid. The wedge bonded hydrogen at C3 is labeled pro-R and the dash bonded hydrogen is labeled pro-S.

    Note: In the place of H3C should read Ph=Phenyl group

    Exercise \(\PageIndex{2}\)

    Identify the indicated faces of carbon atoms in the following molecules as Re or Si:

    (a) The structure of hydroxyacetone. Two arrows, one from the top and other from the bottom, point toward the central carbon. (b) The structure of crotyl alcohol. Two arrows, one from the top and other from the bottom, point toward the central carbon.

    Answer

    (a) The structure of hydroxyacetone. The central carbon is labeled Re face at the top and Si face at the bottom. (b) The structure of crotyl alcohol. The central carbon is labeled Re face at the top and Si face at the bottom.

    Exercise \(\PageIndex{3}\)

    The lactic acid that builds up in tired muscles is formed from pyruvate. If the reaction occurs with the addition of hydrogen to the Re face of pyruvate, what is the stereochemistry of the product?

    The figure shows a reaction where pyruvate converts to lactate.

    Answer

    (S)-Lactate

    Exercise \(\PageIndex{4}\)

    The aconitase-catalyzed addition of water to cis-aconitate in the citric acid cycle occurs with the following stereochemistry. Does the addition of the OH group occur on the Re or Si face of the substrate? What about the addition of the H? Do the H and OH groups add from the same side of the double bond or from opposite sides?

    The figure shows a reaction where cis-aconitate reacts with water in the presence of aconitase to form (2 R, 3 S)-isocitrate.

    Answer

    The −OH adds to the Re face of C2, and −H adds to the Re face of C3. The overall addition has anti-stereochemistry.

    This page titled 5.11: Prochirality is shared under a CC BY-NC-SA 4.0 license and was authored, remixed, and/or curated by OpenStax via source content that was edited to the style and standards of the LibreTexts platform.
