    After completing this section, you should be able to

    1. write an equation to illustrate keto-enol tautomerism.
    2. write a detailed mechanism for acid catalyzed keto-enol tautomerism.
    3. write a detailed mechanism for base catalyzed keto-enol tautomerism.
    4. draw the structure of the enol form of a given carbonyl compound.
    Key Terms

    Make certain that you can define, and use in context, the key terms below.

    • enol
    • keto
    • tautomerism
    • tautomers
    • enolate ion
    Study Notes

    Keto-enol tautomerism was first introduced in the Alkyne Chapter, in the discussion of the hydration of alkynes. You may wish to review this section before proceeding.

    Often, the position of a carbon atom near a carbonyl group is designated using Greek letters. The atom adjacent to the carbonyl is alpha, the next removed is beta and so on. The carbon in the carbonyl group is used as reference point and is not assigned a Greek letter. Likewise, hydrogens bare the same Greek letter as the carbon atoms to which they are attached. α-Hydrogens are bonded to α-carbons and β-hydrogens are bonded to β-carbons etc.

    Greek Lettering.png

    The presence of α-hydrogens in a molecule provides the possibility of certain chemical reactions, which will be discussed in this chapter and the next chapter. Because of this, the ability to identify α-hydrogens is an important skill. As shown below, pentanal has two α-hydrogens. Note that aldehyde hydrogens are not given a Greek letter, they are simply referred to as an aldehyde hydrogen.

    Alpha Hydrogen Example.svg

    α-hydrogens, which are attached to a carbon directly adjacent to a carbonyl group, display unusual acidity. This is almost exclusively due to the resonance stabilization of the carbanion conjugate base, called an enolate, as illustrated in the diagram below. The effect of the the stabilizing C=O is seen when comparing the pKa for the α-hydrogens of aldehydes (~16-18), ketones (~19-21), and esters (~23-25) to that of a typical alkyl C-H bond (~40-50).

    Enolate Resonanace.svg

    Exercise \(\PageIndex{1}\)

    Indicate any α-hydrogens contained in the following molecules:

    Example 1 Questions.svg


    Example 1 Answers.svg

    Keto-enol Tautomerization

    Because of the acidity of α-hydrogens, many carbonyl containing compounds undergo a proton-transfer equilibrium called tautomerism. Tautomers are readily interconverted constitutional isomers, usually distinguished by a different location for an atom or a group. Because tautomers involve the rearrangement of atoms, they are distinctly different than resonance forms, which only differ in the position of bonds and lone pair electrons. This discussion focuses on carbonyl groups with α-hydrogens, which undergo keto-enol tautomerism. Keto implies that the tautomer contains a carbonyl bond while enol implies the presence of a double bond and a hydroxyl group.

    The keto-enol tautomerization equilibrium is dependent on stabilization factors of both the keto tautomer and the enol tautomer. For simple carbonyl compounds under normal conditions, the equilibrium usually strongly favors the keto tautomer (acetone, for example, is >99.999% keto tautomer). The keto tautomer is preferred because it is usually more stable than the enol tautomer by about 45–60 kJ/mol, which is mainly due to the C=O double bond (-749 kJ/mol) being stronger than the C=C double bond (-611 kJ/mol). Because ketones have two alky groups donating electron density into the carbonyl carbon, they tend to be more stable and therefore less apt to form the enol tautomer than aldehydes. For example, propanal is 1000 times more likely to be in its enol tautomer than acetone. With carboxylic acid derivatives, the leaving group tends to stabilize the carbonyl through electron donation which makes the formation of the enol tautomer much less likely. In general, ketones are over 100,000,000 times more likely to be in an enol tautomer form than esters.

    Example Acetone Enol.svg

    Example Popanal Enol.svg

    Example Ethyl Ethanoate Enol.svg

    Aldehydes and symmetrical ketones typically only have one possible enol tautomer while asymmetrical ketones can have two or more. The preferred enol tautomer formed can be often be predicted by considering effects which can stabilize alkenes, such as conjugation and alkyl group substitution. The asymmetrical ketone, 2-methylcyclohexanone has two possible enol tautomers. Of the two tautomers, 2-methyl-1-cyclohexen-1-ol, is the more stable and therefore preferred due to the presence of an additional alkyl substituent. Likewise, 1-phenyl-1-propen-2-ol is the more stable enol tautomer of 1-phenyl-2-propanone due to conjugation with the phenyl ring.

    Example Asymmetrical Enol A.svg

    Example Asymmetrical Enol B.svg


    In certain cases additional stabilizing effects allow the enol tautomer to be preferred in the tautomerization equilibrium. In particular, the 1,3 arrangement of two carbonyl groups can work synergistically to stabilize the enol tautomer, increasing the amount present at equilibrium. The diketone, 2,4-pentanedione, is in its enol form 85% of the time under normal conditions. The positioning of the carbonyl groups allows for the formation of a stabilizing intramolecular hydrogen bond between the hydroxyl group of the enol and the carbonyl oxygen. The alkene group of the enol tautomer is also conjugated with the carbonyl double bond which provides additional stabilization. Both of these stabilizing effects are not possible in the keto tautomer.


    Example 2,4-pentanediol enol.svg

    Another effect which can stabile an enol tautomer is aromaticity. When considering the molecule 2,4-cyclohexadienone, the enol tautomer is the aromatic molecule phenol. The stabilization gained by forming an aromatic ring is sufficient to make phenol the exclusive tautomer present in the equilibrium.

    Example Phenol Enol.svg

    Exercise \(\PageIndex{2}\)

    Please draw all of the possible enol tautomers for the following compounds. If more than one is possible then indicate which is the most stable and why.







    Example 2b Answers.svg


    Mechanism for Catalyzed Keto-Enol Tautomerization

    The enol tautomer has valuable nucleophilic characteristics. In neutral media, tautomerization is slow but it can be speed up by catalysis with acids or bases. Both pathways involve two separate proton transfer steps. Because enols are a key reactive intermediate, these mechanistic steps will be used repeatedly in later reactions. The following mechanistic steps represent the continuous interconversion between the keto and enol tautomers.

    Overall Process

    Reaction overall ketoenol process.svg

    Acidic Conditions

    Keto Tautomer → Enol Tautomer

    In the first step, the carbonyl oxygen is protonated by an acid to form an intermediate oxonium ion. A base removes an α-hydrogen during the second step forming a double bond by an E2 type reaction. This causes the pi electrons of the protonated carbonyl to move to the oxygen to form the hydroxyl group of the enol product and regenerating the acid catalyst.

    1) Protonation of the carbonyl to form an oxonium ion

    Mechanism Acidic Formation Step 1.svg

    2) Deprotonation of an α-hydrogen to form an enol

    Mechanism Acidic Formation Step 2.svg

    Enol Tautomer → Keto Tautomer

    First, one of the lone pairs of electrons on the enol oxygen moves to form a pi bond with the adjacent carbon to create a oxonium ion. This also causes the pi bond electrons from the enol double bond to attack the electrophilic H+ provided by acid catalyst forming a C-H bond in the α-position. This produced oxonium ion intermediate is subsequently deprotonated to form the neutral ketone and regenerate the acid catalyst.

    1) Protonation at the α-carbon

    Mechanism Acidic Keto Formation Step 1.svg

    2) Deprotonation

    Mechanism Acidic Keto Formation Step 2.svg

    Under Basic Conditions

    Keto Tautomer → Enol Tautomer

    In the first step, a base removes an α-hydrogen from a carbonyl containing compound to form an alkene by an E2 like process. The causes the pi electrons of the carbonyl bond to move onto the carbonyl oxygen to form an enolate anion. The oxygen of the enolate anion is protonated in the second step to create a neutral enol and regenerate the base catalyst.

    1) Deprotonation of a α-hydrogen to form an enolate ion

    Mechanism Basic Enol Formation Step 1.svg

    2) Protonation the enolate ion to form an enol

    lMechanism Basic Enol Formation Step 2.svg

    Enol Tautomer → Keto Tautomer

    The mechanistic return to the keto tautomer begins with deprotonation of the hydroxyl hydrogen to produce an enolate ion. Then lone pair electrons from the enolate anion attack an electrophilic H+ through conjugation with the double bond. This simultaneously forms the carbonyl double bond, adds an alpha hydrogen, and regenerates the base catalyst.

    1) Deprotonation of the enol hydrogen

    Mechanism Basic Keto Formation Step 1.svg

    2) Protonation of the α-carbon

    Mechanism Basic Keto Formation Step 2.svg

    Biological Enol Forming Reactions

    One very important family of isomerase enzymes catalyzes the shifting of a carbonyl group in sugar molecules using a process called an carbonyl isomerization. Carbonyl isomerization often involves converting between a ketose and an aldose. (recall that the terms ketose and aldose refer to sugar molecules containing ketone and aldehyde groups, respectively).

    Carbonyl Isomerization.svg

    Carbonyl Isomerization


    Carbonyl isomerization can only occur if there is an OH group adjacent to the carbonyl. Isomerization forms an ene-diol intermediate which has both OH hydrogens available to be removed to form a carbonyl. If the hydrogen from the original OH group is removed a new carbonyl bond is formed.

    Carbonyl Isomerization mechanism.svg

    Carbonyl isomerization is involved in the metabolism of carbohydrates (starches and sugars) to their eventual conversion to CO2 and H2O. First, starches are broken down into glucose in the digestive tract. In the cells, the first step of the glycolysis pathway involves an enzyme converting glucose to glucose-6-phosphate. This is followed by the enzyme-catalyzed tautomerization of glucose-6-phosphate (an aldose) to fructose-6-phosphate (a ketose) through an enediol intermediate. Notice how the carbonyl has moved from the 1-carbon (terminal) to the 2-carbon.


    Exercise \(\PageIndex{3}\)

    Draw the enol forms of the following molecules.

    1. 4-methylcyclohexanone
    2. Methyl acetate
    3. Butanal
    4. 1-phenyl-2-butanone





    Exercise \(\PageIndex{4}\)

    How many α-hydrogens do each of the molecules from the previous question have? Label them.






    Exercise \(\PageIndex{5}\)

    Draw all of the mono-enol forms for the following molecule. Which ones are most stable? Why?

    Exercise 3 Question.svg


    Additional resonance forms stabilizes this enol. Another explanation is that the enol alkene is conjugated to the carbonyl.

    This enol has fewer resonance forms and is therefore less stable. There is no conjugation between the enol and the ketone.

    Exercise \(\PageIndex{6}\)

    For the following compound please identify the most acidic hydrogen atom. Remember that for an enolate conjugate base to be stabilized through conjugation, the lone pair electrons need to be contained in a p orbital which is parallel to the p orbitals which form the C=O pi bond.

    Question 6.png


    The presence of two methyl groups on one of the α-carbons of the carbonyl means that the two hydrogens on the other α-carbon may be deprotonated to form an enolate. When the indicated axial hydrogen is deprotonated the p-orbital formed is parallel with the carbonyl p-orbitals and can participate in overlap. If the equatorial hydrogen were to be deprotonated, the p-orbital formed would be perpendicular with the carbonyl p-orbitals and prevented from participating in overlap.

    Answer 6.svg

    Exercise \(\PageIndex{7}\)

    Nonconjugated ß, gamma-unsaturated ketones, such as 2-hexen-4-one, can be converted to their α, ß-unsaturated isomers by treatment with an acid catalyst. Please propose a mechanism for this isomerization.

    Question 7.svg


    Answer 7.svg
