Objectives

After completing this section, you should be able to

write an equation to illustrate the preparation of an acid anhydride from an acid halide and the sodium salt of a carboxylic acid.
identify the product formed from the reaction of a given acid halide with the sodium salt of a given carboxylic acid.
identify the acid halide, carboxylate salt, or both, required to prepare a given acid anhydride.
write an equation to describe the reaction of an acid anhydride with each of the following: water, alcohol, ammonia, a primary or secondary amine, lithium aluminum hydride.
identify the product formed when a given acid anhydride is reacted with any of the reagents listed in Objective 4, above.
write a detailed mechanism for the reaction of an acid anhydride with any of the reagents listed in Objective 4, above.
identify the acid anhydride, the nucleophilic reagent, or both, needed to prepare a specified carboxylic acid, ester, amide, or primary alcohol.

Study Notes

The reactions described in this section are, in principle, identical to those discussed in Section 21.4. Once you have understood the mechanism of nucleophilic acyl substitution, these reactions should not present you with any great difficulty, and memorization can be kept to a minimum.

This figure provides a convenient general summary of a few of the reactions described in Section 21.5. Note that from a synthetic perspective the ester‑ and amide‑forming reactions are the most common, so they are the focus of this section.

Diagram of acid anhydride forming different derivatives. Adding water to acid anhydride corms carboxylic acid. Adding an alcohol forms an ester. Adding hydride forms an alcohol. Adding ammonia forms an amide.
